Ultimate ISO G&T wall chart LAMINATED. Display this 24" x36" G&T quick reference chart in public work areas Geometrical Product Specifications (GPS). The chart includes all 14 G&T symbols and illustrates application, measurement setup, data, datum's applications and material modifiers. All major tolerance and datum rules as well as virtual and resultant condition calculations are presented in logical simple to understand language. You will want one of these wall charts wherever your designers, engineering and quality folks work.
Ultimate ISO 1101-2004 G&T wall chart. Display this 24”x36” G&T quick reference chart in public work areas.
The chart includes all 14 GD&T symbols with 17 application illustrations, measurement setup, data, datum’s applications and material modifiers. All major tolerance and datum rules as well as virtual and resultant condition calculations are presented in logical simple to understand language.
Rules for the following are included:
- Geometric Tolerance Hierarchy Chart:
- Regardless of Feature Size (RFS)
- Maximum Material Requirement
- Least Material Requirement
- Free State
- Envelope Requirement
- Common Zone
- Threaded Features Pitch Diameter Rules
- Gear and Splined Features Rules
- Projected Tolerance Rules
- Tolerance Frame
- Theorecticall Exact Dimension
- Datum features
- Datum targets
- Datum Coordinate System (DCS)
- Bonus Tolerance
- Virtual Condition, MMVC, LMVC
- Equations for Tolerance Analysis and Fits
- Datum Measurement
- Straightness
- Flatness
- Roundness
- Profile any Line
- Profile any Surface
- Parallelism
- Perpendicularity
- Amgularity
- Position
- Concentricity (Center Points)
- Coaxiality (axis)
- Circular Run-Out
- Total Run-Out
You will want one of these wall charts wherever drawings are being read. Black and white on 24 lb Bond.
This product was added to our catalog on Friday 24 September, 2021.
